068-919-081A Oil Pressure Switch 0.9 Bar Grey - Audi 100 4000 VW Golf Jetta

Oil Pressure Switch (0.9 Bar) – 068-919-081A

The 068-919-081A is a grey-coded oil pressure switch calibrated to trigger at 0.9 Bar. This single-pin sensor is a fundamental component of the dynamic oil pressure warning system found in many VAG vehicles. It monitors high-RPM oil pressure (typically above 2000 RPM) to ensure the engine is adequately lubricated during driving speeds.

When this switch fails, it often triggers a flashing oil light and an audible warning buzzer in the instrument cluster. Replacing a leaking or electrically faulty switch is a simple yet critical maintenance task to ensure your engine's safety monitoring system remains accurate.

Detailed Vehicle Compatibility

Audi 100:

• 1989, 1990, 1991

Audi 100 Quattro:

• 1989, 1990, 1991

Audi 200:

• 1989, 1990, 1991

Audi 200 Quattro:

• 1989, 1990, 1991

Audi 4000:

• 1985, 1986, 1987

Audi 4000 Quattro:

• 1985, 1986, 1987

Audi 5000:

• 1985, 1986, 1987, 1988

Audi 5000 Quattro:

• 1986, 1987, 1988

Audi 80:

• 1988, 1989, 1990, 1991, 1992

Audi 80 Quattro:

• 1988, 1989, 1990, 1991, 1992

Audi 90:

• 1988, 1989, 1990, 1991

Audi 90 Quattro:

• 1988, 1989, 1990, 1991

Audi A4:

• 1996, 1997

Audi A4 Quattro:

• 1996, 1997

Audi A6:

• 1995, 1996, 1997

Audi A6 Quattro:

• 1995, 1996, 1997

Audi A8:

• 1997, 1998, 1999

Audi A8 Quattro:

• 1997, 1998, 1999

Audi Cabriolet:

• 1995, 1996, 1997

Audi Coupe:

• 1985, 1986, 1987

Audi Coupe Quattro:

• 1990, 1991

Audi Quattro:

• 1985

Audi S4:

• 1992, 1993, 1994

Volkswagen Cabriolet:

• 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993

Volkswagen Corrado:

• 1990, 1991, 1992

Volkswagen EuroVan:

• 1993, 1995

Volkswagen Fox:

• 1987, 1988, 1989, 1990, 1991, 1992, 1993

Volkswagen Golf:

• 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998

Volkswagen Jetta:

• 1985, 1986, 1987, 1988, 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2010, 2011

Volkswagen Passat:

• 1990, 1991, 1992, 1993

Volkswagen Quantum:

• 1985, 1986, 1987, 1988

Volkswagen Scirocco:

• 1985, 1986, 1987, 1988

Volkswagen Vanagon:

• 1986, 1987, 1988, 1989, 1990, 1991

---

Product Highlights & Features

• Accurate 0.9 Bar Rating: Specifically designed to function with the high-RPM warning buzzer system in classic water-cooled engines.

• OEM Color Coding: The grey plastic housing makes for easy identification during installation, ensuring the correct pressure range is used.

• Corrosion Resistant: Features a durable metal housing and high-quality electrical terminal to resist heat and engine bay chemicals.

Technical Specifications

• Part Number: 068-919-081A

• Pressure Rating: 0.9 Bar

• Thread Size: M10 x 1.0

• Color: Grey

• Connection: 1-Pin Blade

---

Installation & Maintenance Tips

• Washer Replacement: Always use a new aluminum or copper crush washer to ensure a leak-proof seal against the oil filter housing.

• Torque Specification: Hand-tighten and then snug with a wrench (approx. 20-25 Nm). Do not over-torque, as the threads in the oil filter flange can strip easily.

• Wire Inspection: Before installing, check the single wire lead for cracked insulation or a loose spade connector, as these often cause "phantom" oil warnings.
