EMPI Oil Shock, Front, Link Pin, Lowered

EMPI Lowered Front Shock – Chrome, Oil-Filled for Link Pin VW Type 1 (1954–1965 Beetle & Ghia)

Part Number: 00-4451-0

Upgrade your lowered VW front suspension with EMPI’s oil-filled lowered front shock, designed specifically for Type 1 models with link pin front ends. This shock absorber is ideal for vehicles lowered more than 3 inches using an adjustable beam, helping to prevent bottoming out and improve ride quality.

Shock Dimensions:

• Closed Length: 9 3/4"
• Extended Length: 14 5/8"
• Eyelet Inner Diameter: 12mm (fits mounts approx. 11.9mm)

Fitment:

• 1954–1965 VW Beetle
• 1956–1965 Karmann Ghia
  (Link pin front end only)

Features:

• Designed for lowered front ends with adjustable beams
• Oil-filled for smooth damping and durability
• Chrome finish for a clean, custom look
• Includes 12mm eyelet sleeves for easy mounting
• Sold individually
• May arrive painted white or red depending on EMPI’s current supplier—functionality remains the same

Installation Tip:
If the shock won’t fit the lower mount, check for rusted sleeves from the old shock. Removal may require vice grips, heat, a chisel, or a cut-off wheel.

Shock Absorber Guide:

• Front:
  • Stock Height – Use stock shock
  • Drop Spindles – Use stock shock
  • Lowered >3" with adjustable beam – Use lowered shock (this product)
• Rear:
  • Stock length rear shocks typically work for most lowered applications
