111-827-171 VW Beetle Decklid Hinge Bracket Plate - M6-1.0 Threaded (1950-1979)

VW Decklid Hinge Bracket / Threaded Plate – 111-827-171

The 111-827-171 is the internal threaded reinforcement plate used to secure the decklid (engine lid) hinges to the vehicle body. On a classic Beetle, the hinge bolts pass through the hinge itself and the bodywork, threading into these moveable plates located inside the engine compartment's upper channel. Because these plates are hidden and often exposed to moisture and heat, the M6-1.0 threads frequently strip or the plate itself becomes heavily corroded, making it impossible to tighten or align the decklid properly.

This replacement bracket is a heavy-duty steel plate featuring precision-cut threads that match the original factory hardware. It is designed to slide into the factory retainer slot, allowing for the slight "float" required to adjust the decklid gaps for a perfect, flush fit. Whether you are dealing with a "spun" nut or a snapped bolt, replacing this plate is the correct way to ensure your engine lid stays securely attached and aligned.

Detailed Vehicle Compatibility This bracket is a universal fit for the Type 1 chassis throughout its entire production run:

VW Beetle (Standard):

• 1950, 1951, 1952, 1953, 1954, 1955, 1956, 1957, 1958, 1959, 1960, 1961, 1962, 1963, 1964, 1965, 1966, 1967, 1968, 1969, 1970, 1971, 1972, 1973, 1974, 1975, 1976, 1977

VW Super Beetle:

• 1971, 1972, 1973, 1974, 1975, 1976, 1977, 1978, 1979

Product Highlights & Features

• Universal Fitment: One part number covers nearly 30 years of Beetle production.

• Precision Threaded: Features clean M6-1.0 threads to prevent cross-threading during installation.

• Structural Steel: Manufactured from heavy-gauge steel to provide the clamping force needed to support the weight of the decklid.

• Adjustable Alignment: Sized to fit within the body channel while allowing enough movement for precise panel gap adjustment.

Technical Specifications

• Part Number: 111-827-171

• Thread Pitch: M6-1.0

• Material: Zinc-Plated or Natural Steel

• Quantity: Sold Individually (2 required per hinge, 4 per car)

Installation & Maintenance Tips

• Don't Forget the Anti-Seize: Apply a small amount of anti-seize lubricant to your hinge bolts before threading them into this new plate. This prevents future rust-welding caused by engine heat.

• Alignment Hack: Keep the bolts slightly loose until the decklid is closed. Align the lid with the body lines, then carefully open it and perform the final tightening of the bolts.

• Check the Hinge Pin: While you have the hinge unbolted to replace the plate, check for side-to-side play in the hinge pin. If the hinge is wobbly, no amount of plate adjustment will make the lid sit straight.

• Replacement Quantity: These are sold individually. It is highly recommended to replace both plates on a single hinge at the same time to ensure uniform thread strength.
