Bosch SR-401X VW Vanagon Starter - 1983-1991 Manual Transmission

Bosch Remanufactured Starter – SR-401X

The SR-401X is the premier choice for owners of manual-transmission Vanagons who want "first-turn" reliability. Because Vanagons often serve as campers and adventure vehicles, a reliable starter is non-negotiable. This Bosch unit is a closed-nose design with a counterclockwise rotation, specifically optimized for the unique flywheel and bellhousing configuration of the 1.9L and 2.1L Wasserboxer engines.

With a 0.95 KW power rating, this starter provides snappy engagement even in cold weather. As a remanufactured unit, it represents an eco-friendly choice that doesn't sacrifice quality, as every wearable component is replaced with brand-new, high-quality parts.

Detailed Vehicle Compatibility

VW Vanagon (Manual Transmission Syncro):

1983, 1984, 1985, 1986, 1987, 1988, 1989, 1990, 1991

Product Highlights & Features

• Start/Stop Compatible: Designed to handle the high-cycle demands of modern driving and automatic start/stop operations.

• Lightweight Aluminum Housing: Features an aluminum nose cone and housing for superior heat dissipation and reduced weight (approx. 11.5 lbs).

• Direct OE Replacement: Recommended as an Original Equipment replacement for all 1983–1991 manual Vanagon models.

Technical Specifications

• Part Number: SR-401X

• Voltage: 12V DC

• Power Rating: 0.95 KW

• Rotation: Counterclockwise (Left)

• Mounting: 2-Bolt Flange

Installation & Maintenance Tips

• Battery Connection: Before installing, ensure your battery is fully charged and the terminals are clean. A weak battery or corroded cables can mimic a starter failure and place unnecessary strain on the new unit.

• The "Big Wire" Check: Inspect the main battery cable and the ground strap between the transmission and the chassis. Vanagons are notorious for ground-path issues; a fresh ground strap ensures the SR-401X receives full amperage.

• Registration: Don't forget to register your unit with Bosch immediately after purchase to activate the Ultimate Protection Plan roadside assistance.
